The Vyne Programming Language
Vyne is a hybrid interpreted language engineered for performance-critical algorithm testing and low-level memory control. Designed in Baku, it provides a clean, C-style syntax with advanced functional primitives.
Engine Rulesets
Vyne allows you to configure engine behavior at runtime using the
ruleset block.
ruleset {
warnings, # Enable/Disable semantic warnings
dynamic_casting # Control strictness of type conversions
};
Types & Variables
Vyne supports both implicit inference and strict explicit typing
using the :: operator.
| Type | Declaration Example | Description |
|---|---|---|
Int64 |
a :: Int64 = 42;
|
64-bit signed integer. |
Float64 |
x :: Float64 =
3.14;
|
Double precision floating point. |
Array |
list :: Array = [1, 2,
3];
|
Dynamic list with native methods. |
String |
s :: String =
"Vyne";
|
UTF-8 compatible strings. |
Control Flow & Logic
Vyne provides standard imperative control structures alongside advanced functional iteration patterns.
Conditionals (If/Else)
Vyne uses standard if, else if, and
else blocks. Braces are mandatory for clarity.
score :: Int64 = 85;
if score >= 90 {
out("Grade: A");
} else if score >= 80 {
out("Grade: B");
} else {
out("Grade: F");
}
Iterative Loops
Standard while loops are used for condition-based
iteration. You can use break to exit early.
i = 0;
while i < 100 {
if i == 50 { break; }
out(i);
i++;
}
Advanced Iteration: through
The through operator is Vyne's signature feature for
data processing. It transforms or filters collections natively.
| Pattern | Keyword | Action |
|---|---|---|
| Mapping | collect |
Transforms every element and returns a new array. |
| Filtering | filter |
Returns only elements that meet a condition. |
| Deduplication | unique |
Removes all duplicate values from the stream. |
| Standard | loop |
Executes a block for each item without returning a value. |
# Unique filter
raw_data = [1, 1, 2, 3, 3];
clean = through item :: raw_data -> unique;
# Fibonacci with through loop
through i :: 0..n -> loop {
next = a + b;
a = b;
b = next;
};
Engine Control: ruleset
Unlike other languages, Vyne allows you to toggle engine-level
features like warnings or
dynamic_casting mid-script.
ruleset {
warnings: on,
dynamic_casting: off
};
Iteration & Through Loops
While Vyne supports standard while loops, its true
power lies in the through operator for functional-style
data processing.
# Standard While
while i < 10 { i++; }
# Through: Filter and Unique
y = [1, 1, 2, 2, 3];
uniques = through item :: y -> unique;
# Through: Collect (Map)
doubled = through x :: [10, 20] -> collect { x * 2 };
Functions
Functions in Vyne are first-class citizens. They support explicit
type checking, type inference, and can be scoped to specific modules
using the :: operator.
{} are mandatory for function bodies, and the
return keyword is used to exit with a value.
Defining Functions
Vyne allows you to define functions with strict typing for parameters and return values, or you can let the engine infer the types dynamically.
# 1. Explicitly Typed Function
fn add(a :: Int64, b :: Int64) -> Int64 {
return a + b;
}
# 2. Type Inference (Dynamic)
fn multiply(x, y) {
return x * y;
}
# 3. Recursive Logic
fn factorial(n :: Int64) -> Int64 {
if n <= 1 { return 1; }
return n * factorial(n - 1);
}
Function Scoping (Namespacing)
To organize logic, you can bind functions directly to a module. This prevents naming collisions in large projects.
module MathUtils;
# Scoping a function to MathUtils
fn :: MathUtils square(x :: Int64) -> Int64 {
return x * x;
}
out(MathUtils.square(7)); # Outputs: 49
Type Checking Table
| Feature | Syntax | Behavior |
|---|---|---|
| Parameter Typing | (var :: Type) |
Strict validation at call-time. |
| Return Type | -> Type |
Ensures the returned value matches the signature. |
| Void Functions | fn name() { ... } |
Implicitly returns a Null value if no return is
present.
|
| Recursion | factorial(n-1) |
Fully supported with engine-level stack protection. |
Interfaces & Methods
Interfaces in Vyne are more than just structs; they support methods
with self reference and pointer-based relationships.
interface Node {
kind :: Int64,
data :: Int64,
left :: Node&, # Reference type
right :: Node&
isValid() {
if self.data == 0 { return false; }
return true;
}
}
Modular Architecture
Organize large projects using module and
group. Use deploy to expose namespaced
logic to the global scope.
module physics;
group Constants :: physics {
pi :: Float64 = 3.1415;
};
deploy physics;
out(Constants.pi);
Linear Algebra (vlinalg)
The vlinalg module provides high-level abstractions for
vector spaces and matrix operations, leveraging Vyne's functional
primitives for heavy numerical computations.
vlinalg ideal for MLP and
Neural Network prototyping.
Defining Architectures
Use interface to define custom mathematical structures.
The vlinalg.Types
group includes standard definitions for Matrices and Vectors.
interface Vector {
x :: Int64,
y :: Int64,
magnitude() -> Float64 {
return vmath.sqrt(self.x * self.x + self.y * self.y);
}
}
Matrix Operations
Vyne excels at matrix transformations by combining
through loops with collect or
loop patterns.
| Operation | Function | Description |
|---|---|---|
| Addition | vlinalg.add(a, b) |
Element-wise addition of two matrices. |
| Multiplication | vlinalg.multiply(a, b) |
Standard dot product multiplication ($O(n^3)$). |
| Activation | vlinalg.apply_sigmoid(m) |
Applies sigmoid function to all elements. |
| Transpose | vlinalg.transpose(m) |
Swaps rows and columns. |
Practical Usage: Matrix Multiplication
module vlinalg;
deploy vlinalg;
# Initialize a 2x2 Matrix
m1 = Types.Matrix(2, 2, [[1, 2], [3, 4]]);
m2 = Types.Matrix(2, 2, [[5, 6], [7, 8]]);
# Perform dot product
result = multiply(m1, m2);
out(result.data); # [[19, 22], [43, 50]]
VCore (System Standard)
The vcore module is the backbone of the Vyne runtime,
providing essential utilities for I/O, process management, and
environment introspection.
| Method | Signature | Description |
|---|---|---|
input |
(prompt) -> String |
Pauses execution and reads a line from stdin. |
now |
() -> String |
Returns current system time in ISO format. |
sleep |
(ms :: Int64) |
Blocks the current thread for specified milliseconds. |
platform |
() -> String |
Returns OS and Architecture (e.g., "Windows x64"). |
System Properties
| Property | Type | Description |
|---|---|---|
vcore.pid |
Float64 |
The current Process ID. |
vcore.memory_usage |
Float64 |
Physical memory (RSS) consumed by the engine in bytes. |
vcore.version |
String |
Vyne engine semantic version. |
VMath (Numerical Primitives)
Native C++ math implementations for heavy numerical tasks.
vmath
functions operate on 64-bit precision floats.
module vmath;
deploy vmath;
val = sin(3.14 / 2); # Approx 1.0
active = sigmoid(0.5); # High-perf activation
rand_val = random(1, 100);
Function Index
| Category | Methods |
|---|---|
| Trigonometry |
sin, cos, tan,
asin, acos, atan2
|
| Calculus/Log |
sqrt, log, log10,
exp, pow
|
| Machine Learning |
sigmoid, relu, clamp
|
| Rounding |
floor, ceil, round,
abs
|
Mathematical Constants
| Constant | Value |
|---|---|
vmath.pi |
$3.141592653589793$ |
vmath.e |
$2.718281828459045$ |
vmath.tau |
$6.283185307179586$ |
vmem (Memory Engine)
The vmem module provides native introspection and raw
memory manipulation capabilities. It allows Vyne to behave as a
systems-level tool for debugging heap structures.
peek and
poke bypass the safety of the Vyne runtime. Incorrect
addresses will lead to a C++ segmentation fault.
Core Functions
| Method | Signature | Description |
|---|---|---|
usage |
() -> Int64 |
Returns the total deep-memory footprint in bytes. |
addrOf |
(any) -> Int64 |
Returns the native memory address of a Vyne object. |
peek |
(addr) -> any |
Reads a Value from a raw memory address. |
poke |
(addr, val) |
Writes a Value directly to a memory address.
|
Example: Memory Manipulation
module vmem;
deploy vmem;
target = "Original";
addr = vmem.peek(target);
# Directly overwrite the value in memory
vmem.poke(addr, "Injected via vmem");
out(target); # Outputs: Injected via vmem
vglib v0.0.4-alpha
vglib is Vyne's high-performance graphics, audio, and physics ecosystem. Engineered on a multi-threaded C++ backend, it bridges the gap between high-level Vyne scripting and raw hardware power.
Hybrid 2D/3D Pipeline
Seamlessly switch between native OpenGL 3D modes and high-speed texture rendering with Z-buffer support.
Shader Stack
Native GLSL support for Bodycam filters, VHS glitches, VHS-Color correction, and Volumetric Fog.
Nextbot AI (BETA)
Built-in vglib.pathfind() utilizing dynamic
grid-avoidance for high-tension chase sequences.
Architect Suite
Native .dat map loader and OBJ exporter for modular
level design and external engine porting.
module vglib;
module vaudio;
module vmath;
# Initialize high-end bodycam environment
vglib.init(1920, 1080, "Vyne Pro - Selena Nextbot", vglib.FULLSCREEN);
vhs_shader = vglib.load_shader("shaders/vhs.fs");
selena_tex = vglib.load_texture("assets/selena.jpg");
# Global AI State
bot_pos = [60.0, 1.8, 60.0];
walls = vglib.load_map("tau_map.dat");
while (vglib.running()) {
cam_pos = vglib.get_pos(camera);
# AI Neural Tick: Pathfind through modular walls
res = vglib.pathfind(bot_pos, cam_pos, walls, 1.0);
bot_pos[0] = bot_pos[0] + res[0] * 0.4;
bot_pos[2] = bot_pos[2] + res[2] * 0.4;
# 3D Render with VHS Post-Processing
vglib.begin_texture_mode(screen_target);
vglib.begin3d(cam);
vglib.billboard(cam, selena_tex, bot_pos, 4.0, vglib.WHITE);
through w :: walls -> loop {
vglib.cube_texture(wall_tex, w[0], w[1], w[2], w[3], vglib.WHITE);
}
vglib.end3d();
vglib.end_texture_mode();
}
Module Reference: vglib
| Method | Parameters | Description |
|---|---|---|
vglib.load_map(path) |
string |
Parses .dat files and returns an array of
modular world blocks.
|
vglib.pathfind(start, target, map, size)
|
list, list, array, float |
Native AI routine for obstacle avoidance in modular environments. |
vglib.billboard(cam, tex, pos, size) |
ptr, ptr, list, float |
Renders a 2D texture always facing the camera (Ideal for Nextbots). |
vglib.check_collision_map(pos, size, map)
|
list, list, array |
Iterates through world data for high-speed AABB sliding collision. |
vglib.export_obj(map, filename) |
array, string |
Bakes modular world data into a standard 3D mesh (OBJ format). |
Technical Constants
| Constant | Type | Value / Mapping |
|---|---|---|
vglib.VSYNC |
System |
0x00000040 - Synchronization Hint |
vglib.LEFT_SHIFT |
Input |
340 - Standard Sprint Mapping |
vglib.CYAN |
Color |
0x00AAFFFF - Vyne Standard Branding Color
|
Vyne Builder (CLI)
Vyne includes a native deployment tool designed to package your projects into standalone, distributable environments. The builder automatically resolves dependencies, bundles assets, and generates bootstrap scripts.
Usage
Execute the builder via the primary compiler CLI using the
-b flag.
# Synthesizing a standalone release qovluğu
./vynec.exe --build-game main.vy
Deployment Pipeline
When vynec -b is invoked, the engine executes the
following high-speed deployment sequence:
| Phase | Action | Output |
|---|---|---|
| 1. Workspace Init | Creates a dynamic output directory based on script name. | /main_release/ |
| 2. Binary Injection |
Copies vynec.exe and urage.dll to
the root.
|
Engine Binaries |
| 3. Asset Discovery |
Regex-based scanning of strings for
.png, .wav, .fs, .dat, etc.
|
Virtualized Assets |
| 4. Bootstrap Generation |
Writes a run.bat to handle interpreted
execution.
|
Executable Script |
